Fan: DC; axial; 24VDC; 80x80x25mm; 69.29m3/h; 33dBA; Vapo; 3200rpm SUNON
Product Code: MF80252V1-G99-A
The photo is for illustration only. Please refer to the description for exact product specifications.
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Fan: DC; axial; 24VDC; 80x80x25mm; 69.29m3/h; 33dBA; Vapo; 3200rpm SUNON
Useful information
Specifications
Supplier product description
Fan: DC; axial; 24VDC; 80x80x25mm; 69.29m3/h; 33dBA; Vapo; 3200rpm
Useful information
Supplier parameters
Brand
SUNON
Supplier's product code
MF80252V1-G99-A
Product ID
U-256237
Additional functions
Autorestart
Current rating
65mA
Enclosure material
thermoplastic
Fan dimensions
80x80x25mm
Fan efficiency
69.29m<sup>3</sup>/h
Fan motor
brushless DC
Flammability rating
UL94V-0
Impeller material
thermoplastic
Kind of Bearing
Vapo
Kind of fan
axial
Lead length
0.315m
Leads
leads x3
Manufacturer
SUNON
Min. insulation resistance
10MΩ
Noise level
33dBA
Operating temperature
-10...70°C
Operating voltage
8...27.6V DC
Power consumption
1.68W
Rotational rate/speed
3200rpm
Signal output
F type
Static pressure
4.57mm H<sub>2</sub>O
Supply voltage
24V DC
Type of fan
DC
Wire size
24AWG
Product code
MF80252V1-G99-A
