Relay: interface; DPDT; Ucoil: 230VAC,220VDC; 50mA; 0.05A/30VAC PHOENIX CONTACT
Product Code: PLCRPT230UC/2121AU
The photo is for illustration only. Please refer to the description for exact product specifications.
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Relay: interface; DPDT; Ucoil: 230VAC,220VDC; 50mA; 0.05A/30VAC PHOENIX CONTACT
Useful information
Specifications
Supplier product description
Relay: interface; DPDT; Ucoil: 230VAC,220VDC; 50mA; 0.05A/30VAC
Useful information
Supplier parameters
Product code
PLCRPT230UC/2121AU
Brand
PHOENIX CONTACT
Supplier's product code
PLCRPT230UC/2121AU
Product ID
U-2359008
AC contacts rating @R
0.05A / 30V AC
Body dimensions
14x80x94mm
Coil voltage max.
264.5V AC
Coil voltage min.
179.4V AC
Contact material
AgNi + Au
Contacts configuration
DPDT
DC contacts rating @R
0.05A / 36V DC
Electrical connection
push-in terminals
IP rating
IP20
Manufacturer
PHOENIX CONTACT
Manufacturer series
PLC-RPT
Max. operating current
50mA
Mechanical durability
30000000 cycles
Mounting
for DIN rail mounting
Operating temperature
-40...55°C
Rated coil voltage
220V DC
Relay variant
interface
Switched voltage
max. 30V AC
Type of relay
interface
