Hikvision standing display DS-D4218MI-070H(B)
Product Code: MDSD4218MI070HB
The photo is for illustration only. Please refer to the description for exact product specifications.
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Hikvision standing display DS-D4218MI-070H(B)
Specifications
Supplier product description
- LED monitor
- Model: Hikvision DS-D4218MI-070H(B)
- Type: Built-in interactive screen
- Point size: 1.8 mm
- Resolution: 320 × 900
- Dimensions: 613 × 1695.5 × 68.1 mm
- Product Model
- Product ModelDS-D4218MI-070(B)
- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP1.8
- Pixel Pitch1.875 mm
- Modules ComponentCabinet × 5, single cabinet (2 × 4)
- Dimensions (W × H × D)613 × 1695.5 × 68.1 mm (24.1 × 66.8 × 2.7 inch)
- Resolution320 × 900
- Area1.0125 m²
- Weight29 kg (64.0 lb.)
- Pixel Density284444 dots/m²
- Lamp Board HousingWithout housing, glue potting
- Cabinet MaterialAluminum alloy
- Maintenance MethodFront maintenance for cabinet, and rear maintenance for system backpack
- Display
- White Balance Brightness600 cd/m²
- Color Temperature3000 to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 160°
- Contrast Ratio≥ 3000:1
- Color Uniformity± 0.003 Cx, Cy
- Brightness Uniformity≥ 97%
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 16 bit
- Power
- Power Supply110 to 220 VAC ± 15％
- Max. Consumption≤ 345 W/m²
- Average Consumption＜115 W/m²
- Working Environment
- Working Temperature-10 to 40 °C (14 to 104 °F)
- Working Humidity10% to 60% RH (non-condensing)
- Storage Humidity10% to 85% RH (non-condensing)
- Storage Temperature-20 to 60 °C (-4 to 140 °F)
- General
- Package Dimension (W × H × D)1831 × 1082 × 246 mm (72.1 × 42.6 × 9.7 inch)
- Gross Weight69 kg (152.12 lb.)
- Packing ListPower cord × 1, HDMI × 1, Wi-Fi antenna × 2
Supplier parameters
Product code
MDSD4218MI070HB
Category
M
Brand
Hikvision
Supplier's product code
MDSD4218MI070HB
Product ID
U-4133550
