Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8" UNI-T
Product Code: MSO2202
The photo is for illustration only. Please refer to the description for exact product specifications.
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8" UNI-T
Useful information
Specifications
Supplier product description
Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Useful information
Supplier parameters
Product code
MSO2202
Supplier's product code
MSO2202
Product ID
U-3845384
Band
200MHz
Dimensions
370x185x115mm
Display resolution
800x480
Input coupling
AC, DC, GND
Input impedance
1MΩ/16pF
Input sensitivity
500µV/div...20V/div
Interface
LAN
Kind of display used
LCD TFT 8"
Manufacturer
UNI-T
Measuring instrument features
mathematical functions: addition, subtraction, division, multiplication and FFT
Memory record length
56Mpts
Number of channels
2
Related items
MSO/UPO2000-AUTO
Rise time
≤1.8ns
Sampling
2 Gs/s
Standard equipment
USB cable
Supply voltage
100...240V AC
Time base
1n...1ks/div
Type of oscilloscope
digital
Trigger
video signal
Vertical resolution
8bit
Brand
UNI-T
