Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 1A/120VAC; 2A/24VDC RELPOL

Product Code: RSM822-P-12
The photo is for illustration only. Please refer to the description for exact product specifications.

Price range

AmountPrice with tax (pcs)
1-4
6.506.50
5-19
5.95
20-99
4.70
100-499
4.35
500+
3.85
wholesale

Min. qty: 1

Multiplier: 1

Total:

6.50
2025-07-15 Estimated delivery

*Total delivery cost will be calculated in the checkout.

Warehouse in Europe

Warehouse in Europe

90% positive feedback

94%+ positive feedback

30 day money back guarantee

30 day money back guarantee

Product description

RELPOL
Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 1A/120VAC; 2A/24VDC RELPOL

Specifications

SKU
U-314046
Brand
Product code
RSM822-P-12

Supplier product description

Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 1A/120VAC; 2A/24VDC

Supplier parameters

Product code
RSM822-P-12
Brand
RELPOL
Supplier's product code
RSM822-P-12
Product ID
U-314046
AC contacts rating @R
1A / 120V AC
Body dimensions
21x10.1x12.1mm
Coil power consumption
200mW
Coil resistance
720Ω
Coil voltage max.
18V DC
Coil voltage min.
9V DC
Contact current max.
2A
Contact material
AgPd/Au 0,2μm
Contact resistance
100mΩ
Contacts configuration
DPDT
DC contacts rating @R
2A / 24V DC
Electrical life
100000 cycles
IP rating
IP64
Manufacturer
RELPOL
Manufacturer series
RSM822
Mechanical durability
10000000 cycles
Mounting
PCB
OEM number
2611734
Operate time
4ms
Operating temperature
-30...80°C
Rated coil voltage
12V DC
Relay variant
miniature
Release time
4ms
Switched voltage
max. 24V DC
Terminal pitch
5mm
Type of relay
electromagnetic
