Product description
Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; 20A; 20A/125VAC HONGFA RELAY
Useful information
Specifications
Supplier product description
Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; 20A; 20A/125VAC
Useful information
Supplier parameters
Product code
HF152FD/012-1H
Brand
HONGFA RELAY
Supplier's product code
HF152FD/012-1H
Product ID
U-204149
AC contacts rating @R
20A / 125V AC
Body dimensions
21x16x20.6mm
Coil power consumption
360mW
Coil resistance
400Ω
Coil voltage max.
15.6V DC
Coil voltage min.
9V DC
Contact current max.
20A
Contact material
AgNi
Contact resistance
100mΩ
Contacts configuration
SPST-NO
Manufacturer
HONGFA RELAY
Mounting
PCB
Operate time
10ms
Operating temperature
-40...105°C
Rated coil voltage
12V DC
Relay variant
subminiature
Release time
5ms
Switched voltage
max. 400V AC
Type of relay
electromagnetic
