Product description
Switch: vandal resistant; Pos: 2; SPDT; 2A/24VDC; IP65; ON-ON; 300mm E-SWITCH
Useful information
Specifications
Supplier product description
Switch: vandal resistant; Pos: 2; SPDT; 2A/24VDC; IP65; ON-ON; 300mm
Useful information
Supplier parameters
Actuator colour
silver
Backlight colour
red/green/blue
Body colour
silver
Body dimensions
Ø22x30.7mm
Button height
1.8mm
Button marking
blank
Button shape
flat
Contact plating
silver plated
Contacts configuration
SPDT
DC contacts rating @R
2A / 24V DC
Electrical life
50000 cycles
Illumination
LED
IP rating
IP65
Key stroke
2.8mm
Lead length
0.3m
Leads
cables
Manufacturer
E-SWITCH
Manufacturer series
PV4
Max. contact resistance
:50mΩ
Mechanical durability
1000000 cycles
Min. insulation resistance
1GΩ
Mounting
on panel
Mounting hole diameter
Ø19mm
Number of positions
2
Operating temperature
-20...55°C
Panel thickness
max. 11mm
Stable positions number
2
Switching method
ON-ON
Type of switch
vandal resistant
Product code
PV4FW30SS-3R5
Brand
E-SWITCH
Supplier's product code
PV4FW30SS-3R5
Product ID
U-2735205
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: .
