Capacitor: polypropylene; 470pF; 2kVDC; 700VAC; 5x12.5x18mm; THT WIMA
Product Code: FKP1-470P/2000
The photo is for illustration only. Please refer to the description for exact product specifications.
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Capacitor: polypropylene; 470pF; 2kVDC; 700VAC; 5x12.5x18mm; THT WIMA
Useful information
Specifications
Supplier product description
Capacitor: polypropylene; 470pF; 2kVDC; 700VAC; 5x12.5x18mm; THT
Useful information
Supplier parameters
Product code
FKP1-470P/2000
Supplier's product code
FKP1-470P/2000
Product ID
U-189543
Body dimensions
5x12.5x18mm
Capacitance
0.47nF
Capacitor application
high frequency circuits
Capacitors features
low dielectric loss factor
Climate class
55/100/56
Flammability rating
UL94V-0
Kind of material
flame retardant
Manufacturer
WIMA
Max. operating voltage
2kV DC
Mounting
THT
Operating temperature
-55...100°C
Pulse resistance
56kV/μs
Terminal pitch
15mm
Type of capacitor
polypropylene
Tolerance
±5%
Brand
WIMA
